Big, bigger, DST – Manufacturer of permanent magnetic couplings produced massive and heavy magnetic coupling and a large double wall canister
The torque of the magnetic coupling is approximately 15,000 Nm at 20°C. The corresponding double wall canister is designed for a working pressure of 16 bar. The canister also has provisions to monitor the operation giving the customer a safe and realiable operation run. The total weight of the shipment was more than two tons.
The magnetic coupling was designed using standard guidelines and was checked for feasibility using latest simulations software. Among others, torque, eddy current losses and stiffness simulations for various load conditions have been made. By now, DST has more than 1,000 different magnet configurations.
Published: August, 09 2019
